Polyester Conveyor Belt
Created with Pixso. Filtration Sludge Dewatering Polyester Conveyor Belt Horizontal Vacuum Belt Filter

Filtration Sludge Dewatering Polyester Conveyor Belt Horizontal Vacuum Belt Filter

Brand Name: SPEK
MOQ: 1pc
Price: 100~1000usd
Delivery Time: 2-10working days
Detail Information
Place of Origin:
Hebei,China
Certification:
ISO901-2000
Material:
100% Polyester
Usage:
Powder Filter
HS Code:
59100000
Type:
Plain
Techniques:
Woven
Size:
OEM, Customizing Is Welcome
Color:
White, Blue, Red
Capacity:
99% Filter Dehydration
Package:
Plastic Woven Bag
Suitable Range:
For Waste Water Sludge Dewatering
Packaging Details:
plastic bags
Supply Ability:
20000square meters
Highlight:

woven fabric mesh belt

,

filter conveyor belt

,

Vacuum Polyester Conveyor Belt

Product Description
Product Description




1. Advantages:
High quality
Excellent filtration function
Good stripping, high stability, not easy deformation
Smooth surface
Clogging protection and durable


2 .Application:
Sludge dehydration
Juice squeeze
Paper pulp
Mine tailings disposal
Belt filter cloth mainly matching with belt type filter press, vacuum rubber belt filter and hirizontal vacuum belt filter.


3 Why choose us?
Computerized weaving process
1 Annual maximal weaving capacity:from 250 000 up to 500 000 m.
2 Heavy looms from 4 up to 13 m wide.

Controlled thermostabilisation process
1 Capacity: width (10 m) - length (160 m)
2 Process whole trace ability

Neat fishing
1 Final cut accurately matching the width required.
2.Belts seams: clipper (hooks) - loop - weaved
3 Glued edges
4 Guiding profiles

Laboratory test
1 Air permeability measurement
2 Mechanical resistance measurement.
3 Electron microscope




Type

Filament diameter

      mm

Density/root

      cm

Tensile strength

     N/cn

Weight

Kg/M²

Thickness

   mm

Air permeability

m³/m²h

CFM

127/pa

um
Warp  weft warp weft surface joint
27508- Flat Yarn 6*0.18+0.50 28.5 25 2200 1000 1.20 1.95 1600 100 58-80
27508-1

Flat

Yarm

600D long yarn+0.50 28.5 21 2200 1000 0.90 1.9 720 45 20-50







Filtration Sludge Dewatering Polyester Conveyor Belt Horizontal Vacuum Belt Filter 0Filtration Sludge Dewatering Polyester Conveyor Belt Horizontal Vacuum Belt Filter 1
