Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner

Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner
Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner

Large Image :  Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner

Product Details:
Place of Origin: Jiangsu China
Brand Name: SPEK
Certification: SGS
Model Number: 0.25mm
Payment & Shipping Terms:
Minimum Order Quantity: 24pcs
Price: 2-50usd
Packaging Details: standard export cartons
Delivery Time: 2-10working days
Supply Ability: 3000m2 per week

Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner

Description
Color: Tan Black Temp Resistance: -140 °C To + 260°C
Properties: Ultra-Violet, Infra-red, Micro-Wave,adio Frequency Resistance Thickness: 0.25mm
Standard Width: 12" 24" 36" 48" Thermal Expansion: Low Thermal Expansion: < 5%
Surface Resistance (Ω/m2): Insulative Coating Adhesion (N/5cm): 30
Warp Tongue Tear Strength (N): 30 Coated Fabric Thickness: 0.13mm
PTFE Coating %: 58% Adhesive Weight (g/m2): 55
Warp Tensile Strength (g/m2): 2500 Warp Tear Strength(N): 30
Slit Widths: 1/4" Width Or Wider In 1/16" Increments Bonded Surface: Metals, Plastics,glass, Rubber, Wood And Other Surface
High Light:

PTFE Adhesive Backed Tape

,

Heat Resistant PTFE Adhesive Backed Tape

,

Yellow Release Liner Adhesive Backed Ptfe

PTFE Adhesive Backed Tape With Yellow Release Liner Easy Release And Heat Resistance

Teflon coated fiberglass fabric with Adhesive tape  PTFE coated fiberglass with one side coated silicon pressure sensitive adhesive tapes for temperature resistanceup to 260°C. This product offers excellent self adhering properties eliminating the need of secondary gluing procedures, it can be used on heat sealing equipment . It has a continuous service temperature of 260°C and can be put through a thermos setting cycle. This cycle is generally 4 hours long and requires the adhesive to be heated to 200°C. The tape has a crinkled yellow release liner for ease of removing which also ensures the adhesive is well protected prior to use.

  • Main features:
    * High temperature resistance (140℃ to 360℃)
    * Non-stick and easy to clean.
    * Food grade and non-toxic.
    * Light transmission rate up to 6% – 13%.
    * Good dimensional stability and high strength.
    * Good mechanical properties.
    * Corrosion-resistant, acid resistance, anti-aging.
    * High insulation properties (Low dielectric constant: 2.6; Tangent < 0.0025 ), anti-UV, anti-static.
    * Flame retardant.

                               Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner 0




PTFE adhesive tapes application: they are most frequently used in heat sealing applications within the packaging industry for covering the sealing jaws in packaging machines.

.Impulse sealers

.Form and Fill sealers

.L Bar Sealers

.Side sealers

.Blister packs

Other applications include lining chutes, guide rails and everywhere you require a highly slippery surface.



                          Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner 1



                               Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner 2

                                Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner 3

                               Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner 4

                               Heat Resistant PTFE Adhesive Backed Tape With Yellow Release Liner 5
