| Place of Origin: | Qingdao, Shandong |
|---|---|
| Brand Name: | SPEK |
| Certification: | CE ISO9001 |
| Model Number: | SP-135 |
| Minimum Order Quantity: | 1set |
| Price: | 10000~200000usd |
| Packaging Details: | Suitable for transportation by sea |
| Delivery Time: | 30-50working days |
| Supply Ability: | 10set per month |
| Processing Type: | EPE Foaming Machine | Condition: | New |
|---|---|---|---|
| Product Type: | PE Foam Sheet, Rod | Raw Material: | LDPE |
| Computerized: | Non-Computerized | Processing Material: | PE |
| Screw Type: | Single Screw | HS Code: | 84772090 |
| Autoation: | Semi-Automatic | Screw Diameter: | 135mm |
| Delivery Time: | 35 Working Days | Transport Package: | Suitable For Transportation By Sea |
| Foaming Rate: | 20-60 | Foaming Additive: | Butane Gas, GMS,EPE Foaming Masterbatch |
| High Light: | epe foam sheet extrusion line,pvc foam sheet machine |
||
I. Main Information
1. Gurantee: 2 years
2. Certificate: CE, ISO
3. Energy saving 30-40%
4. Sharing 85% domestic market
5. Delivery: 35 working days
6. Running machines everyday
II. Product Introduction
This machine is of advanced structure with reliable performance and high-grade automation. It is easy to handle and maintain.
And its output is high, being the preferable model compared with the domestic similar machine in performance and price.
The products made by this equipment are widely applied to the packing industry, such as the electronic circuit board, electric
products, high-grade furniture, motorcycles, shoes-making, wooden floor, cases and bags, hardwares, bicycles, automobiles, pottety,
glass wares etc.
Main Technical Specification
| Model | SP-90 | SP-105 | SP-120 | SP-135 | SP-150 | SP-170 | SP-180 | SP-200 | |
| Screw diameter | mm | 90 | 105 | 120 | 135 | 150 | 170 | 180 | 200 |
| Width | mm | 1000-1650 | 1000-1650 | 1000-1650 | 1000-1650 | 1000-1650 | 1000-1650 | 1000-1650 | 1000-1650 |
| Thickness | mm | 0.3~4 | 0.5~6 | 0.8~8 | 1~10 | 2~12 | 2~14 | 5~16 | 10~25 |
| Output | kg/hr | 60-80 | 80-150 | 120-160 | 150-180 | 200-350 | 300-450 | 350-500 | 500-650 |
| Foaming additive | Butane gas, GMS,EPE foaming masterbatch | ||||||||
| Installed capacity | kw | 63 | 45 | 90 | 105 | 168 | 198 | 200 | 220 |
| Installed dimension | mm | 18×2×2.4 | 18×2×2.4 | 23×2×2.4 | 26×2×2.4 | 26×2×2.4 | 28×2×2.4 | 30×2×2.4 | 32×2×2.4 |
