Insulating Plain Woven PTFE Coated Fiberglass Fabric 1200mm Max Width

Basic Information
Place of Origin: Hebei,China
Brand Name: SPEK
Model Number: S9035AJ
Minimum Order Quantity: 1M2
Price: 30~800usd
Packaging Details: cartons or pallets
Delivery Time: 2-10working days
Supply Ability: 100000 square meters per month
Detail Information
Thickness: 0.15mm Max Width: 1200mm
Weave Type: Plain Woven Yarn Type: E-glass
Alkali Content: Alikali Free Working Temperature: -140-260℃
Color: Black, Brown, Milk Brown,or Customized Surface Treatment: PTFE Coated
High Light:

fiberglass woven fabric


ptfe coated glass fibre fabric

Product Description

Product Description

Based on high-quality fiberglass basic cloth, to coat PTFE resin then making it into various PTFE high temperature resistance clothes in different thickness and width.Fiberglass fabric coated with PTFE has various good capability and it is widely used in aircraft industry, paper manufacture, food, environment protection, print and painting, costume, chemical, glass manufacture, medical, electronic, insulation, building (basic cloth of topping frame), sharpener slice, machinery, etc.

1, Good temperature resistance
It can be used under the temperature of -70 to 260, which has the capability of weather resistant and age resistant. Under practical situation of high temperature of 250 for 200 days, not only the intensity will not decrease, the weight will not reduce; If putting it under the high temperature of 350 for 120 hours, the weight only decreased by about 0.6%; Under the situation of -180, it will not be chapped and keep the original pliability;
2. Non stickness,
Hardly to adhere any material; It is easy to wash away the blot or other dust such as resin, coating material, etc.
3. Chemical corrosion resistant
It could resist acid, alkali, aqua fortis and various kinds of organic liquid corrosion; And it almost to resisting all kinds of medicament.
4, Stable dimension, high intensity, elongation coefficient less 5%.
5, Low coefficient of friction and dielectric constant,good insulating ability.

1. Used as various of liners to resist high temperature, such as microwave liner, oven liner, food drying or other liners.
2. High insulation of electric: Insulating belt of electric, septa, cushion, gasket. High frequency plank coated with copper;
3. Heat resisting envelope, enswathing of heat insulation;
4. Binding of all sorts of petroleum and chemical pipeline to resist eroding, environmental sulfur separating of exhaust gas of electric factory;
5. It could be made into static resisting fabric.


Styles and Specifications:

Item Color Thickness Max Width Weight Tensile Strength Temperature resistance
S908AJ brown 0.08mm 1.25m 165g/㎡ 550/450N/5cm -140~260℃
S908BJ black 0.08mm 1.25m 170g/㎡ 550/450N/5cm -140~260℃
S913AJ brown 0.13mm 1.25m 260g/㎡ 1100/1000N/5cm -140~260℃
S913BJ black 0.13mm 1.25m 275g/㎡ 1100/1000N/5cm -140~260℃
S915AJ brown 0.15mm 1.25m 380g/㎡ 1200/1000N/5cm -140~260℃
S918AJ black 0.18mm 1.25m 395g/㎡ 1800/1700N/5cm -140~260℃
S925AJ brown 0.25mm 3.20m 490g/㎡ 2100/1800N/5cm -140~260℃
S925BJ black 0.25mm 3.20m 510g/㎡ 2100/1800N/5cm -140~260℃
S935AJ brown 0.35mm 3.20m 660g/㎡ 2600/2300N/5cm -140~260℃
S935BJ black 0.35mm 3.20m 680g/㎡ 2600/2300N/5cm -140~260℃
S940AJ milk white 0.40mm 3m 780g/㎡ 3000/2500N/5cm -140~260℃
S940BJ black 0.40mm 3m 820g/㎡ 3000/2500N/5cm -140~260℃
S965AJ milk white 0.65mm 3m 1150g/㎡ 4400/4000N/5cm -140~260℃
S990AJ milk white 0.90mm 3m 1550g/㎡ 6000/5000N/5cm -140~260℃
S990BJ black 0.90mm 3m 1650g/㎡ 6000/5000N/5cm -140~260℃

Insulating Plain Woven PTFE Coated Fiberglass Fabric 1200mm Max Width 0Insulating Plain Woven PTFE Coated Fiberglass Fabric 1200mm Max Width 1
