| Place of Origin: | Hebei,China |
|---|---|
| Brand Name: | SPEK |
| Certification: | SGS |
| Model Number: | S9040AJ |
| Minimum Order Quantity: | 1M2 |
| Price: | 30~800usd |
| Packaging Details: | pack in roll with polybag, then in cartons |
| Delivery Time: | 2-10working days |
| Supply Ability: | 200000meters per week |
| Material: | Glassfiber Fabric | Weave: | Plain Woven |
|---|---|---|---|
| Adhesive: | Acrylic | Color: | Brown And Black |
| Max Width: | 1250mm | Feature: | Heat-Resistant |
| Sample: | Free Sample | Tensile Strength: | 550N/5CM~5000N/5CM |
| Yarn Type: | E -glass | Coating: | PTFE Coating |
| High Light: | fiberglass woven fabric,ptfe coated glass fibre fabric |
||
|
PTFECoated Fiberglass Fabrics We use best imported Fiberglass yarn as the weaving material to plain knit or specially knit into superior fiberglass basic cloth, coat it with fine PTFE resin then make it into various PTFE fabric in different thickness and widths. PTFE coated fiberglass fabric applications: PTFE fabric could be used as various of liners to resist high temperature, such as microwave liner, oven liner, or other liners. used as non stick liners, intermediate. used as various conveyor belts, fusing belts, sealing belts or anywhere need resisting high temperature, non stick, chemical resistance etc. used as covering or wrapping material in petroleum, chemical industries, as wrapping material, insulating material, high temperature resistance material in electrical industries, desulfurizing material in power plant etc. PTFE coated fabrics general properties: 1. Outstanding temperature resistance 2. Excellent chemical resistance 3. Superior non-stick surface, easy to clean 4. High dielectric strength 5. Dimensional stability 6. Resistance to UV, IR and HF 7. Non-toxic
|
|
| Styles and Specifications: | |
|
Item
|
Color
|
Thickness
|
Max Width
|
Weight
|
Tensile Strength
|
Temperature resistance
|
|
S908AJ
|
brown
|
0.08mm
|
1.25m
|
165g/㎡
|
550/450N/5cm
|
-140～260℃
|
|
S908BJ
|
black
|
0.08mm
|
1.25m
|
170g/㎡
|
550/450N/5cm
|
-140～260℃
|
|
S913AJ
|
brown
|
0.13mm
|
1.25m
|
260g/㎡
|
1100/1000N/5cm
|
-140～260℃
|
|
S913BJ
|
black
|
0.13mm
|
1.25m
|
275g/㎡
|
1100/1000N/5cm
|
-140～260℃
|
|
S915AJ
|
brown
|
0.15mm
|
1.25m
|
380g/㎡
|
1200/1000N/5cm
|
-140～260℃
|
|
S918AJ
|
black
|
0.18mm
|
1.25m
|
395g/㎡
|
1800/1700N/5cm
|
-140～260℃
|
|
S925AJ
|
brown
|
0.25mm
|
3.20m
|
490g/㎡
|
2100/1800N/5cm
|
-140～260℃
|
|
S925BJ
|
black
|
0.25mm
|
3.20m
|
510g/㎡
|
2100/1800N/5cm
|
-140～260℃
|
|
S935AJ
|
brown
|
0.35mm
|
3.20m
|
660g/㎡
|
2600/2300N/5cm
|
-140～260℃
|
|
S935BJ
|
black
|
0.35mm
|
3.20m
|
680g/㎡
|
2600/2300N/5cm
|
-140～260℃
|
|
S940AJ
|
milk white
|
0.40mm
|
3m
|
780g/㎡
|
3000/2500N/5cm
|
-140～260℃
|
|
S940BJ
|
black
|
0.40mm
|
3m
|
820g/㎡
|
3000/2500N/5cm
|
-140～260℃
|
|
S965AJ
|
milk white
|
0.65mm
|
3m
|
1150g/㎡
|
4400/4000N/5cm
|
-140～260℃
|
|
S990AJ
|
milk white
|
0.90mm
|
3m
|
1550g/㎡
|
6000/5000N/5cm
|
-140～260℃
|
|
S990BJ
|
black
|
0.90mm
|
3m
|
1650g/㎡
|
6000/5000N/5cm
|
-140～260℃
|
