Non stick , dying, drying, digital printing PTFE coated Fiberglass Fabric

Basic Information
Place of Origin: Hebei,China
Brand Name: SPEK
Certification: SGS
Model Number: H925J
Minimum Order Quantity: 1M2
Price: 30~800usd
Delivery Time: 2-10working days
Supply Ability: 200000meters per week
Detail Information
Material: Glassfiber Fabric Type: Flat Belt
Adhesive: Acrylic Color: Brown And Black
Max Width: 1250mm Feature: Heat-Resistant
Sample: Free Sample Tensile Strength: 550N/5CM~5000N/5CM
High Light:

fiberglass woven fabric

,

ptfe glass mesh fabric


Product Description

PTFE Coated Fiberglass Fabrics

We use best imported Fiberglass yarn as the weaving material to plain knit or specially knit into superior fiberglass basic cloth, coat it with fine PTFE resin then make it into various PTFE fabric in different thickness and widths.

PTFE coated fiberglass fabric applications:

PTFE fabric could be used as various of liners to resist high temperature, such as microwave liner, oven liner, or other liners. used as non stick liners, intermediate. used as various conveyor belts, fusing belts, sealing belts or anywhere need resisting high temperature, non stick, chemical resistance etc. used as covering or wrapping material in petroleum, chemical industries, as wrapping material, insulating material, high temperature resistance material in electrical industries, desulfurizing material in power plant etc.

PTFE coated fabrics general properties:

1. Outstanding temperature resistance
(from -170°C to +260°C)

2. Excellent chemical resistance

3. Superior non-stick surface, easy to clean

4. High dielectric strength

5. Dimensional stability

6. Resistance to UV, IR and HF

7. Non-toxic



Styles and Specifications:
Item
Color
Thickness
Max Width
Weight
Tensile Strength
Temperature resistance
H908AJ
brown
0.08mm
1.25m
165g/㎡
550/450N/5cm
-140~260℃
H908BJ
black
0.08mm
1.25m
170g/㎡
550/450N/5cm
-140~260℃
H913AJ
brown
0.13mm
1.25m
260g/㎡
1100/1000N/5cm
-140~260℃
H913BJ
black
0.13mm
1.25m
275g/㎡
1100/1000N/5cm
-140~260℃
H915AJ
brown
0.15mm
1.25m
380g/㎡
1200/1000N/5cm
-140~260℃
H918AJ
black
0.18mm
1.25m
395g/㎡
1800/1700N/5cm
-140~260℃
H925AJ
brown
0.25mm
3.20m
490g/㎡
2100/1800N/5cm
-140~260℃
H925BJ
black
0.25mm
3.20m
510g/㎡
2100/1800N/5cm
-140~260℃
H935AJ
brown
0.35mm
3.20m
660g/㎡
2600/2300N/5cm
-140~260℃
H935BJ
black
0.35mm
3.20m
680g/㎡
2600/2300N/5cm
-140~260℃
H940AJ
milk white
0.40mm
3m
780g/㎡
3000/2500N/5cm
-140~260℃
H940BJ
black
0.40mm
3m
820g/㎡
3000/2500N/5cm
-140~260℃
H965AJ
milk white
0.65mm
3m
1150g/㎡
4400/4000N/5cm
-140~260℃
H990AJ
milk white
0.90mm
3m
1550g/㎡
6000/5000N/5cm
-140~260℃
H990BJ
black
0.90mm
3m
1650g/㎡
6000/5000N/5cm
-140~260℃
