High Temperature PTFE Coated Fiberglass Fabric Heat Resistant Fiberglass

I'm Online Chat Now

High Temperature PTFE Coated Fiberglass Fabric Heat Resistant Fiberglass

China High Temperature PTFE Coated Fiberglass Fabric Heat Resistant Fiberglass supplier
High Temperature PTFE Coated Fiberglass Fabric Heat Resistant Fiberglass supplier High Temperature PTFE Coated Fiberglass Fabric Heat Resistant Fiberglass supplier High Temperature PTFE Coated Fiberglass Fabric Heat Resistant Fiberglass supplier High Temperature PTFE Coated Fiberglass Fabric Heat Resistant Fiberglass supplier

Large Image :  High Temperature PTFE Coated Fiberglass Fabric Heat Resistant Fiberglass

Product Details:

Place of Origin: Taizhou,Jiangsu
Brand Name: SPEK
Certification: SGS
Model Number: S9040AJ

Payment & Shipping Terms:

Minimum Order Quantity: 50meters
Price: usd1~usd10
Packaging Details: pack in roll with polybag, then in cartons
Supply Ability: 200000meters per week
Contact Now
Detailed Product Description
Material: Glassfiber Fabric Weave: Plain Woven
Adhesive: Acrylic Color: Brown And Black
Max Width: 1250mm Feature: Heat-Resistant
Sample: Free Sample Tensile Strength: 550N/5CM~5000N/5CM
Yarn Type: E -glass Coating: PTFE Coating

PTFECoated Fiberglass Fabrics

We use best imported Fiberglass yarn as the weaving material to plain knit or specially knit into superior fiberglass basic cloth, coat it with fine PTFE resin then make it into various PTFE fabric in different thickness and widths.

PTFE coated fiberglass fabric applications:

PTFE fabric could be used as various of liners to resist high temperature, such as microwave liner, oven liner, or other liners. used as non stick liners, intermediate. used as various conveyor belts, fusing belts, sealing belts or anywhere need resisting high temperature, non stick, chemical resistance etc. used as covering or wrapping material in petroleum, chemical industries, as wrapping material, insulating material, high temperature resistance material in electrical industries, desulfurizing material in power plant etc.

PTFE coated fabrics general properties:

1. Outstanding temperature resistance
(from -140°C to +260°C)

2. Excellent chemical resistance

3. Superior non-stick surface, easy to clean

4. High dielectric strength

5. Dimensional stability

6. Resistance to UV, IR and HF

7. Non-toxic



Styles and Specifications:
Item
Color
Thickness
Max Width
Weight
Tensile Strength
Temperature resistance
S908AJ
brown
0.08mm
1.25m
165g/㎡
550/450N/5cm
-140~260℃
S908BJ
black
0.08mm
1.25m
170g/㎡
550/450N/5cm
-140~260℃
S913AJ
brown
0.13mm
1.25m
260g/㎡
1100/1000N/5cm
-140~260℃
S913BJ
black
0.13mm
1.25m
275g/㎡
1100/1000N/5cm
-140~260℃
S915AJ
brown
0.15mm
1.25m
380g/㎡
1200/1000N/5cm
-140~260℃
S918AJ
black
0.18mm
1.25m
395g/㎡
1800/1700N/5cm
-140~260℃
S925AJ
brown
0.25mm
3.20m
490g/㎡
2100/1800N/5cm
-140~260℃
S925BJ
black
0.25mm
3.20m
510g/㎡
2100/1800N/5cm
-140~260℃
S935AJ
brown
0.35mm
3.20m
660g/㎡
2600/2300N/5cm
-140~260℃
S935BJ
black
0.35mm
3.20m
680g/㎡
2600/2300N/5cm
-140~260℃
S940AJ
milk white
0.40mm
3m
780g/㎡
3000/2500N/5cm
-140~260℃
S940BJ
black
0.40mm
3m
820g/㎡
3000/2500N/5cm
-140~260℃
S965AJ
milk white
0.65mm
3m
1150g/㎡
4400/4000N/5cm
-140~260℃
S990AJ
milk white
0.90mm
3m
1550g/㎡
6000/5000N/5cm
-140~260℃
S990BJ
black
0.90mm
3m
1650g/㎡
6000/5000N/5cm
-140~260℃
