Double Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - Corrosion

I'm Online Chat Now

Double Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - Corrosion

China Double Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - Corrosion supplier
Double Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - Corrosion supplier Double Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - Corrosion supplier Double Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - Corrosion supplier

Large Image :  Double Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - Corrosion

Product Details:

Place of Origin: Taizhou,Jiangsu
Brand Name: SPEK
Certification: SGS
Model Number: TS535

Payment & Shipping Terms:

Minimum Order Quantity: 50meters
Price: usd5~usd20
Packaging Details: packed in cartons
Supply Ability: 100000meters per week
Contact Now
Detailed Product Description
Materail: Silicone Coated Glassfiber Farbic Color: Red, Grey,black, White
Max Width: 1500mm Alkali Content: Mdeium
Withstand Temperature: -50°C To +230°C Weave: Plain Woven
Yarn Type: E-glass,C-Glass Coating: Double Sides Coating,one Side Coating

Silicone coated fiberglass fabric has quite similar characteristics to those of PTFE coated fiberglass fabric.But they are more flexible,very non-stick,non-slip surface and more tear resistance. These fabric are available coated on one side and both side in red, gray, black etc color available in 0.1mm to 3mm thickness.

Properties
  • Superior Release Non-stick surface
  • High temp resistant up to 230째C
  • Excellent release properties
  • Superior abrasion resistance
  • Good heat insulation
  • Good chemical resistance
  • Good dielectric properties
  • Good weather ability

Silicone fiberglass fabric applications:

  • Electric insulation: Silicon coated fiberglass fabric features high grade of electric insulation and bear a load of high voltage. It fits for making products like insulation cloth and sleeves etc.
  • Non-metallic compensator: silicone fiberglass fabric could be used as pipeline flexible coupling, non-metallic compensator helps to avoid damage caused by heat expansion and cold contraction. This membrane material specially fit for use in industries of petroleum, chemical engineering, cement, iron and steel and energy sources due to its special features of temperature resistance, anti-corrosion, anti-aging, and good elasticity and toughness.
  • Anti-corrosion sector: silicone fiberglass fabric is good to be used as inner and outer anti-corrosion layer featuring excellent corrosion resistance, temperature resistance and high strength. It proves to be an ideal anti-corrosion material.
  • Others: Apart from above application, silicone fiberglass fabric can also be used as sealing material, temperature resistant and anti-corrosion conveyer belt and packaging material.

Styles and Specifications:



Item
Thickness
Breaking Strength (N/50mm)
Bursting strength
(Mpa)
Flammability
Width
Colour
TS515
0.15mm
1500/1200
2.0
≤25%
0-1250
White
TS518
0.18mm
1600/1300
2.0
≤25%
0-1250
White/red
TS525
0.25mm
1800/1500
2.1
≤25%
0-1250
White/red/black
TS535
0.35mm
1900/1550
2.2
≤25%
0-1250
White/red/black
TS540
0.40mm
2000/1600
2.2
≤25%
0-1500
White/red/black
TS550
0.50mm
2200/1800
2.3
≤25%
0-1500
White/red/black
TS560
0.60mm
2400/2200
2.4
≤25%
0-1500
White/red/black
TS570
0.70mm
2500/2300
2.4
≤25%
0-1500
White/red/black
TS580
0.80mm
2600/2400
2.5
≤25%
0-1500
White/red/black
TS590
0.90mm
2800/2600
2.5
≤25%
0-1500
White/red/black
TS5100
1.00mm
3000/2800
2.6
≤25%
0-1500
White/red/black
TS5120
1.20mm
3400/3000
2.5
≤25%
0-1500
White/red/black
TS5150
1.50mm
3700/3300
2.3
≤25%
0-1500
White/red/black

Double Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - CorrosionDouble Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - CorrosionDouble Sides Silicone Coated Fiberglass Fabric Electric Insulation Anti - Corrosion
